HYUNDAI iX35 Front Lower Left Control Arm

Online
Catalog

PDF
Catalog

New
Products

Home Catalog Control Arm HYUNDAI iX35 (JE, JK) 2010 - 2015 HYUNDAI iX35 (JE, JK) 2010 - 2015 Control Arm

HY6068 /

Front Lower Left /

Assembly Parts

HY1019
Ball Joint

HY11040
Control Arm Bushing

HY11042
Control Arm Bushing

‹ ›

Product Details

Product Code	HY6068
Chassis (Front / Rear)	Front
Position	Lower Left
Other Side	HY6067
Weight	4,953 kg / 10.92 lb
Material Type	Metal
Ball Joint Cone Size [mm]
Ball Joint BallPin Thread Size
Note

Other Parts of the Linked Vehicles

HYUNDAI iX35 JE, JK 2010 - 2015

PRODUCT CODE	PRODUCT NAME	POSITION
HY1019	BALL JOINT	FRONT LOWER LEFT AND RIGHT
HY2038	TIE ROD END	FRONT RIGHT
HY2039	TIE ROD END	FRONT LEFT
HY3034	AXIAL JOINT	FRONT LEFT AND RIGHT
HY4057	LINK STABILIZER	FRONT LEFT AND RIGHT
HY4057X	LINK STABILIZER	FRONT LEFT AND RIGHT
HY4058	LINK STABILIZER	REAR LEFT AND RIGHT
HY4080	LINK STABILIZER	FRONT LEFT AND RIGHT
HY6067	CONTROL ARM	FRONT LOWER RIGHT
HY6067J	CONTROL ARM	FRONT LOWER RIGHT
HY6068J	CONTROL ARM	FRONT LOWER LEFT
HY9001	CONTROL ARM	REAR UPPER LEFT AND RIGHT
HY9010	CONTROL ARM	REAR LOWER LEFT AND RIGHT
HY9019	CONTROL ARM	REAR UPPER
HY11010	CONTROL ARM BUSHING	REAR LOWER RIGHT
HY11011	CONTROL ARM BUSHING	REAR LOWER LEFT
HY11040	CONTROL ARM BUSHING	LEFT AND RIGHT
HY11042	CONTROL ARM BUSHING	CENTER LEFT AND RIGHT
HY11043	CONTROL ARM BUSHING	LEFT AND RIGHT
HY11075	CONTROL ARM BUSHING	REAR UPPER
MZ11045	CONTROL ARM BUSHING	REAR LOWER
HY12066	AXLE SUPPORT BUSHING	REAR
HY12040	REAR CARRIER (TORSION) BUSHING	REAR LEFT AND RIGHT
HY12057	STABILISER MOUNTING	FRONT
HY12057K	STABILISER MOUNTING	FRONT
HY12063	STABILISER MOUNTING	FRONT
HY12063K	STABILISER MOUNTING	FRONT
HY12065	ENGINE MOUNTING	RIGHT
HY12100	ENGINE MOUNTING	LEFT
HY12101	ENGINE MOUNTING	REAR
KI12021	ENGINE MOUNTING	LEFT
KI12022	ENGINE MOUNTING	REAR LOWER
HY13003	STEERING BELLOW	FRONT

Also Fits In

HY6068 / CONTROL ARM

MAKE	MODEL	BODY TYPE & YEAR
HYUNDAI	iX35	JE, JK 2010 - 2015
KIA	SPORTAGE	SL 2010 - 2015

OEM Codes

HY6068 / CONTROL ARM

OEM CODES
54500-2S000 54500-2Y000 54500-2Y001 54500-2Y002

Quick Search

* Name of all vehicles, brands, models, symbols and logos, OE numbers and other third party numbers in this website and catalog are used for reference purposes only.
